Explosion vent
for hygienically
demanding processes.

EGV HYP

for zero to low negative pressure applications.

With the vent panel EGV HYP which is designed for production facilities with highly elevated hygienic requirements, REMBE^® is able to provide safety and cleanliness Made in Germany. The innovative sealing concept of the EGV HYP is able to convince. Deposits and bacterial growth are permanently prevented. A direct mounting of the vent panel to round vessel forms is also possible due to pre-bending.

Application

The EGV HYP was specially designed for hygienically demanding systems in the food and pharmaceutical industry, and is often used in critical systems such as spray and fluidbed dryers. The special feature: The patented, full-flat, chamfered gasket system has a flush internal sealing area with the vent panel, and facilitates the avoidance of cross-contamination.

New:
Gasket optionally available in contrasting blue.

RSK signalling unit

The retrofit signaling unit with tear wire.

view product

Advantages

Hygienic design will continuously assure a high product quality.
Protects against cross-contamination when changing products.
Enables CIP cleaning.
Increased service life of the vent panel under alternating temperature and pressure stresses through the integrated bionic structure.
Reduces sound emissions (e.g. from hammers) at the venting channels.

Mechanism

In case of a sudden pressure increase, the EGV HYP vent panel will open and release the pressure from the vessel.

Technical data

Product parameters

Standard burst pressure P_stat	0,1 bar
Max. permitted operating pressure	50 % of P_stat
Temperature	− 40 to + 180 °C (− 40 to + 356 °F)
Material	Stainless steel
Gasket material	Full-scale silicon seal (FDA-licensed, hygienic performance)
Tolerance	± 20 % at standard burst pressure
Process	Non-pulsating
Recommended torque for M10 screws	15 - 20 Nm

Our specialists will be pleased to assist you in finding a solution that matches your specific operating conditions.

Dimensions and weight

Max. size of wall opening – nominal vent dimensions, mm	Effective venting area, cm²
305 x 610	1860
490 x 590	2890
586 x 920	5400
610 x 1118	6800
920 x 920	8500
915 x 1118	10230
1000 x 1000	10000
1020 x 1020	10400

Other sizes available on request.

Applications + Industries

animal feed productions
aspiration plants
chemical- petrochemical
food
food production
mixers
pharmaceutical industry
spray dryers

Downloads

Certifications

SIL-Equivalent

SIL 4

ATEX EC type
examination certificate no. FSA 04 ATEX 1538 X

Tested according to EHEDG

The specially developed sealing system prevents product deposits. The outside is insulated to prevent condensation-related product built-up.

Click and drag image to view.

view in AR

Scan the QR code with your iOS camera* to see an AR preview of the product. EGV HYP AR Viewer Ru

The dimensions shown may differ from those of the actual product.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.

Werner Przywara, production specialist in explosion vents for hygiene applications

Werner Przywara, Produktionsspezialist Hygieneberstscheiben

"I’ve been building the EGV HYP ever since it was first developed. I recently had a visit from a customer who shared his experience with me. Apparently he had installed the EGV HYP in his spray dryers a few years ago, and he was still very pleased. So I was really happy to hear that."
